180C 2.5mm VDE Fiberglass Insulated Copper Wire H05SS-K

  • 180C 2.5mm VDE Fiberglass Insulated Copper Wire H05SS-K
Place of Origin Guangdong，China
Brand Name Mysun
Certification UL/cUL/CCC/CE/RoHS/SGS
Model Number VED H05SS-K
Minimum Order Quantity 3050meters
Price 0.06~0.48USD per M
Packaging Details Standard packge: cardboard box Accept custom-made.
Delivery Time 7-15 working day
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 500000 Meters per Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Conductor Type Stranded Color White
Usage Widely Used In Home Appliance ,lighting ,heater,motor & Generator,UAU,robot,industrial Power Etc Rated Voltage 450/750v
Rated Temperature 180C Size 2.5MM
Conductor Tinned Copper Certification ROHS/CCC/VDE/CCC/ISO9001:2008
Standard VDE 0282-3 Insulation Silicone Rebber
Type Insulated Max.Cond Resistance 7.16 Ω/KM
Construction 50/0.254
Highlight

2.5mm Fiberglass Insulated Copper Wire

,

VDE Fiberglass Insulated Copper Wire

,

180C Tinned Copper Insulated Wire
Leave a Message
Product Description

2.5mm VDE H05SS-K silicone wires and cable with VDE certificate



 VDE H05SS-K  Specifications:

Nominal voltage:450/750V

Temperature range: 180℃

Standard: VDE H05SS-K

Insulation: Silicone Rubber

Conductor: Tinner copper





Product features:

insulated wire has excellent resistance to high temperature, low temperature resistance, excellent electrical insulation performance,

high voltage resistance, aging resistance, long service life and soft and easy to install.







Product Parameter



Applications:

* Widely used in lighting, household appliances, , lamps.
* electric appliances, instrumentation, motor wiring and electronics.
* gas appliances and other high-temperature environment.



Conductor Insulation Diameter
(mm)		 Max.Cond Resistance Unit length
Size
(AWG)		 Construction
(No./mm)		 Diameter
(mm)		 First insulation thickness
(mm)		 Second insulation thickness
(mm)		 (Ω/KM) (M)(Ft)
0.5 16/0.2 0.75 0.6 0.6 3.15 40.1 200/656
0.75 24/0.2 1.13 0.6 0.6 3.53 26.7
1 32/0.2 1.31 0.6 0.6 3.71 20
1.5 30/0.254 1.6 0.8 0.7 4.6 13.7
2.5 50/0.254 2.08 0.8 0.7 5.28 7.16


Our Product



180C 2.5mm VDE Fiberglass Insulated Copper Wire H05SS-K 0



Product Description



180C 2.5mm VDE Fiberglass Insulated Copper Wire H05SS-K 1

Package & Delivery



Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days



180C 2.5mm VDE Fiberglass Insulated Copper Wire H05SS-K 2







Company Introduction



180C 2.5mm VDE Fiberglass Insulated Copper Wire H05SS-K 3

180C 2.5mm VDE Fiberglass Insulated Copper Wire H05SS-K 4
