UAV heater XLPE Insulated Wire 305M/ Roll UL3321 30AWG Copper Conductor

  • UAV heater XLPE Insulated Wire 305M/ Roll UL3321 30AWG Copper Conductor
  • UAV heater XLPE Insulated Wire 305M/ Roll UL3321 30AWG Copper Conductor
  • UAV heater XLPE Insulated Wire 305M/ Roll UL3321 30AWG Copper Conductor
Place of Origin Guangdong ,China
Brand Name MYSUN
Certification UL
Model Number UL3321
Minimum Order Quantity 3050M
Price 0.1-1.5USD/M
Packaging Details 305M/roll,610M/roll,carton 32cm*32cm*32cm
Delivery Time 7-10working days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1000000 meters per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name UL3321 Color Black Red White
Insulation XLPE Conductor Tinned Copper
MOQ 3050 Certificates UL Certificates
Payment T/T Package 305M/ Roll
Rated Temperature 150C Rated Voltage 600V
Size 30AWG-2AWG
Highlight

UAV heater XLPE Insulated Wire

,

305M/ Roll XLPE Insulated Wire

,

30AWG XLPE Copper Wires
Leave a Message
Product Description

Hook up wires UL3321 XLPE insulated wire tinned copper conductor black red white
UL3321 Specification
rated voltage:600V
rated temperature:150C
Standard:UL758
Insulation:XLPE
Conductor:Tinned copper
Applications:Widely used in home appliance,new energy automobile,lighting,heater,motor&generator,UAV,robot,industrial power etc.
Size:30AWG-2AWG
Color:white,black,red,brown,yellow,blue,green,yellow/green.
note:1-4/0AWG conductor wire,can be specially customized.
UAV heater XLPE Insulated Wire 305M/ Roll UL3321 30AWG Copper Conductor 0
UL3321 demesion:

Conductor Insulation Max.Cond Resistance Unit length
Size
(AWG)		 Construction
(No./mm)		 Diameter
(mm)		 Nominal Thickness
(mm)		 Diameter
(mm)		 (Ω/KM) (M)(Ft)
30 7/0.10 0.30 0.78 1.86 361 305/1000
28 7/0.127 0.38 1.94 227
26 7/0.16 0.48 2.04 143
24 11/0.16 0.60 2.16 89.3
22 17/0.16 0.76 2.32 56.4
20 21/0.18 0.94 2.49 35.2
18 16/0.254 1.18 2.73 22.2
16 26/0.254 1.50 3.06 14
14 41/0.254 1.89 3.45 8.78
12 65/0.254 2.37 3.93 5.53
10 105/0.254 3.02 4.58 3.476
9 133/0.254 3.36 4.92 2.73
8 133/0.28 3.75 1.15 6.05 2.16 100/328

6


 84/0.45 4.79 7.09 1.361
4 133/0.45 6.02 8.32 0.8559
2 212/0.45 7.60 1.53 10.66 0.5384


Benefits of UL3321 :


  • long aging resistance
  • good soft bending performance
  • can be wound for use
  • long service life
  • Good electrical, mechanical and physical properties
  • simple production process, light structure
  • large transmission capacity
  • convenient installation and maintenanceUAV heater XLPE Insulated Wire 305M/ Roll UL3321 30AWG Copper Conductor 1



UAV heater XLPE Insulated Wire 305M/ Roll UL3321 30AWG Copper Conductor 2


Service:
Shipment:
1. by express
2. by sea

Payment terms:
LC, TT, Western Union, Money Gram and PayPal

Delivery:
Sample order: 1-3 working days
Big order: 5-10 working days
Customized order: 10-15 working days

FQA

1. Are you a manufacturer?
A:Yes,Our factory is located in Dongguan City more than 20,000 sqmm;
and have 20 years leading experience in manufacturing wires.

2. What are your main products?
A:Our main products are SR wire,FEP wires ,xlpe pvc wires and Mica wires Wire Harnesses.

3.What certification did your products pass?
A: We attained UL; cUL, CSA;VDE; CCC;IATF 16949;ISO 9001;ISO 14001 ROHS,REACH certifications
